Strain Analysis Services

Element offers strain analysis across a diverse range of materials including composites, glass, ceramics, steels, and alloys. Our expertise spans transportation, defense, aerospace, and industrial sectors, testing everything from individual components to full-size products.

In a stress-strain analysis, we apply strain gages to your product to determine the stresses acting on the part. That allows us to carry out the following kinds of analysis:

• Static and dynamic loading analysis
• Torque strain measurements
• Temperature stress testing (-250°C to +1000°C)
• Fatigue life estimations
• Performance parameter validation

We install and measure strain gages in virtually any condition, including extreme environments such as high temperatures, cryogenic conditions, and liquid immersion. Our cutting-edge data acquisition systems provide:

• Six fully integrated data acquisition systems, each capable of 300+ channels (clarifying system capabilities)
• Real-time data collection supplemented with digital video, CAN & LIN bus protocols
• On-site instrumentation services for international and domestic projects
• Correlation and validation of computer models, including FEA and dynamic modeling

Pioneering Research Advantage

We boast the first industry database for strain-life fatigue in cast iron, demonstrating our commitment to technological innovation and advanced materials research

We provide stress-strain analysis and strain gaging services for products and materials in Transportation, Defense, Aerospace and industrials. From individual components and subsystems to full-size products, we support engineering designs, product validation, strain life predictions and validation of analytical models such as FEA and dynamic modeling.

Our data acquisition and engineering support specialists work with you to create the optimal test procedure, developing plans for evaluating your materials and products that meet the engineering design criteria.

We can install and measure strain gages in virtually any condition, including low and high-temperature environments and immersion in liquids. Our state-of-the-art facilities incorporate:

• Six data acquisition systems with 300+ measurement channels
• Telemetry systems for rotating machinery
• Digital video and communication protocol data recording
• Advanced strain gage installation capabilities
• Computer Model Correlation & Validation
• On-Site/In-Field instrumentation and data acquisition services
• Acquisition systems capability of recording real time data to supplement strain measurements including digital video, CAN & LIN bus protocols
• Strain gage temperature ranges from -250°C to +1000°C
• Application of any strain gage virtually any substrate including composites, glass, ceramics, steels & alloys
• Torque strain gage applications both external and internal shaft installation with telemetry systems for rotating machinery
